Metal roof steel structure is a support system constructed by steel trusses, steel beams, steel columns and so on, using metal sheets as the roof covering layer. It has many advantages such as light weight and high strength, flexible modelling, efficient construction, etc. However, the waterproof problem should not be underestimated. Metal roof panel joints are the first weak point of waterproofing, whether it is transverse or longitudinal plate seams, due to temperature changes, roof vibration and plate processing errors, etc., the joints are prone to gap opening or misalignment, which provide paths for rainwater seepage and leakage. Furthermore, the various connectors and fixings of the roof, such as the combination of self-tapping screws and roof panels, with the passage of time, the screws corrode, the sealant ages, and the rainwater is very easy to seep into the house along the screw holes. In addition, the deformation characteristics of the steel structure, under load, temperature differences, etc. will produce displacement, which is closely linked to the waterproofing of metal roof panels to bring a great test, if the waterproofing measures are not in place, roof leakage will occur frequently.
(1) plate seam waterproofing
Selection of high-quality sealing materials is the key, such as silicone weather sealant, which has excellent ultraviolet resistance, high and low temperature resistance, can adapt to the complex environmental changes in the roof. Construction, you need to clean both sides of the plate seam, remove oil, dust and other impurities, to ensure that the sealant and plate good bonding. Sealant will be injected evenly into the plate seam, filling full, forming a continuous waterproof adhesive strip, the width and depth should meet the design requirements, to prevent rainwater from breaking through this first line of defence. For some special shapes or larger width of the board seam, can be combined with the use of waterproof tape to enhance the sealing effect.
(2) Fixings waterproofing
Self-tapping screws as a common fixed parts, its waterproof treatment is critical. First of all, we should choose high-quality screws with waterproof washers, tighten the installation to the specified torque, so that the washers are fully compressed roof panels, to play a preliminary waterproof role. In the head of the screw and the periphery of the application of sealant, the formation of secondary protection, sealant to cover the head of the screw and extend a certain range, effectively blocking the rain along the screw infiltration channel. Regularly check the screw fastening and sealant status, found loose, cracking timely repair.
(3) node waterproofing
Roof yin and yang corners, gutter, ridge and other node parts are waterproof key concern object. Installation of special yin and yang corner yin and yang corner fittings, these fittings using the bending process, fit tightly, and sealant sealing, to ensure that the rain will not accumulate in this leakage. Gutter as a roof drainage convergence, stainless steel or galvanised steel material, with sufficient strength and corrosion resistance, gutter and roof panels, rain bucket connection parts should be well sealed, the installation of a reasonable slope, to prevent the accumulation of water backflow. The roof ridge is set up at the ridge cover plate, fixed and sealed by buckling and screws to ensure that rainwater can be diverted smoothly on both sides.
3.Daily Maintenance
Regularly inspect the roof, focusing on checking the operating conditions of sealant, waterproof fittings, drainage system, etc., and find and record problems in time.
Before the rainy season, strengthen the frequency of roof inspection, clean up the gutter debris to ensure smooth drainage; repair and reinforce the parts that may leak in advance to ensure that the metal roof steel structure maintains good waterproof performance in the rainy season, and create a dry and comfortable environment for the building interior.
