Space Frame Structure
home Product Space Frame

Rack Automated Warehouses

Product description

Features of Rack Automated Warehousesr are:
1. The steel structure is light in weight, high in strength, and large span.
2. The construction period of steel structures is short, which reduces investment costs accordingly.
3. Steel structure buildings have poor fire resistance and corrosion resistance. Steel structures should not be used in areas with low temperatures.
4. The steel structure building is easy to move and recycle without pollution.

Structure Type

The plane layout and height requirements of the hangar are special, which directly affects the structure of the hangar.
Due to the large span of the hangar, the structural weight (mainly the roof system) accounts for a large proportion of the total load.
If the structural weight can be reduced, obvious economic benefits can be achieved.
The Rack Automated Warehouses has the advantages of high strength, lightweight, small section, good weldability, and simple manufacturing process.

Quick Details

The hangar uses the advantages of tents for flexible and rapid deployment, low cost of ownership, repeated disassembly and assembly, wide application range, diverse and flexible shapes, a rich selection of materials and accessories, and personalized customization, providing a cost-effective solution for aviation hangars; Design and customize professional-level hangar tents and overall equipment plans for different models.

Standard: AISI, ASTM, bs, DIN, GB, JIS Grade: Q235B/Q355B Carbon Steel
Place of Origin: Jiangsu, China Brand Name: SAFS
Model Number: Steel Structures Type: Light, Light Steel Structure Frame
Application: Hangar/Warehouse/Workshop/Sheds/Office Building Tolerance: ±3%
Processing Service: Bending, Welding, Decoiling, Cutting, Punching Product name: rack automated warehouses
Main structure: Section Column Purlin: C/Z Galvanized Steel(Q235)
Surface treatment: Painting or Galvanizing Wall&Roof panel: Steel Sheet or Sandwich Panel
Structure type: Light Portal Frame Structure Certificate: ISO9001:2008 ISO14001:2004
Life span: Up to 50 Years Wind Resistance: 180km/h

1. The whole hangar adopts a steel structure frame. The surroundings can be equipped with hard ABS board walls and sandwich board walls. The entrances and exits can be equipped with blue flexible retractable doors and sliding doors. The overall appearance is beautiful and the safety performance is high. The wind resistance can reach 120 km/h (wind load 0.7 kN/m²), and the structure is sturdy and durable.
2. The support is made of high-strength aluminum alloy 6061/T6, hardness HW≥14, aging oxidation, tensile strength: 290Mpa, yield strength: 270Mpa, elongation: 13%;
3. The roof tarpaulin material adopts shading double-sided PVC synthetic fiber cloth, which is pre-stretched, tarpaulin and aluminum alloy bracket;
    The surface is tight after the connection, completely isolated from ultraviolet rays, waterproof, the thickness of the fabric is 0.76mm, and the weight is 1100g/㎡;
    Tensile strength (warp/weft): 3553/2939N/5cm, tear strength (warp/weft): 462/348N,

    peel strength Degree (longitude/latitude): 118/116N/5cm, applicable temperature: -30℃ to +70℃.

Supply Ability

Supply Ability:  100000 Square Meter/Square Meters per Month    rack automated warehouses

Packaging & Delivery

Packaging Details
Rack Automated Warehouses
1) Steel structure components will be in nude packaging with proper protection.
2) Sandwich panels will be packed with plastic film.
3) Doors and windows will be packed with bubble plastic.
4) Bolts and another accessory will be packed in wood boxes.
Normally is 40’HQ and 40’OT container.
If you have specifical requirements,40GP and 20GP container are ok.
Port
QINGDAO  PORT/LIANYUNGANG PORT/SHANGHAI  PORT
Lead Time :
Quantity(Square Meters) 1 – 2000 2001 – 5000 5001 – 10000 >10000
Est. Time(days) 25 35 45 To be negotiated

Drawings & Quotation

1) Customized design is welcomed.

2) We have an excellent design team. According to the requirements of different projects and clients, we will supply different designs and steel products. In order to give you an exact quotation and drawings, please let us know the following information. We will quote for you promptly.

Basic design requirements of Rack automated warehouses

Basic Design Requirements
1.Project location 5.Length (sidewall,m) 9.Window quantity, size
2.Snow load 6.Width (end wall, m) 10.Door quantity, size
3.Wind load 7.Wall Height (eave, m)

11.Brickwall needed or not. If yes, 1.2m high or 1.5m high

4.Seismic magnitude 8.Middle column allowed or not

12.Crane needed or not

13.Thermal insulation. If yes, EPS, fiberglass wool, Rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former.



   Engineering Design Software:

  AutoCAD,PKPM,MTS,3D3S, Tekla Structures(X steel)V12.0.etc

Items Specifications
Main Steel Frame Column Q235B,Q355B Welded H Section Steel
Beam Q235B, Q355B Welded H Section Steel
Secondary Frame Purlin Q235B C and Z Purlin
Knee Brace Q235B Angle Steel
Tie Rod Q235B Circular Steel Pipe
Brace Q235B Round Bar
Vertical & Horizontal support Q235B Angle Steel, Round Bar, or Steel Pipe
Maintenance System Roof Panel

EPS, Glass Fiber, Rock Wool, Pu Sandwich Panel

Corrugated Steel Sheet

Wall Panel

EPS, Glass Fiber, Rock Wool, Pu Sandwich Panel

Corrugated Steel Sheet

Accessories Window Aluminum Window, Plastic Steel Window
Door Aluminum Door, Rolling Metal Door
Rainspout PVC
Fastener High Strength Bolts, Normal Bolts, Chemical Bolts
Ventilation System Natural Ventilator, Ventilation Shutters
Live Load on Roof In 120kg Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-Resistance 8 Grades
Structure Usage Up to 50 years
Temperature Suitable temperature -50°C~+50°C
Certification CE, SGS,ISO9001:2008,ISO14001:2004
Finishing Options A vast array of colors and textures available





Main Characters

  • Quick and flexible assembly.

All the components will be prefabricated in the factory before transported to the construction site. The installation process is quick and easy.

  • Cost- effective.

It will significantly shorten the construction period of your buildings, saving a great deal of time and money.

  • High safety and durability.

The steel structure has a lightweight but high strength, which is also easy to maintain. It can be utilized for over 50 years.

  • Optimal design.

The rack automated warehouses can be isolated against outdoor environments as well as avoid any leak like water seepage. It also has excellent fire resistance and corrosion resistance.

  • High utilization.

It is easy to move and relocate steel structure, which can also be recycled without pollution.

  • Solid construction.

The rack automated warehouses is capable of withstanding the attack of strong winds and heavy snow. It also has the excellent seismic performance.

The steel columns and steel beams of the internal frame are made of H-shaped steel through-bolt connection. This kind of building has lightweight, high strength, and large span. The exterior wall panels are made of lapped colored steel veneers, with a service life of 50-100 years. The attachment is made of colored steel, which has a good sealing effect. The wall and roof of the hangar are maintained by glass wool sandwich panels. The hangar has strong fire resistance and avoids the fire. The mainframe of the hangar is connected by bolts, which are simple to install. We can provide for installation. Technical Support. Regarding the transportation of the steel components of the hangar, we use the whole packing box to avoid the damage of the steel components during transportation.
