Space Frame Structure
home Product Space Frame

Dome Coal Storage System

Product description

Span: 122.66m
Height: 68 m
Wind speed: 60 m/s
Earthquake proof: grade 8
Anti-rust treatment: hot-dip galvanization
Roof: color steel sheet
Warranty: 50 years

Quick Details

Standard: AISI, ASTM, bs, DIN, GB, JIS
Grade: STEEL
Place of Origin: Jiangsu, China
Brand Name:
Model Number: CS001
Type: Light
Application: Structural Roofing
Tolerance: ±5%
Processing Service: Bending, Welding, Decoiling, Cutting, Punching
Product Name:

Dome Coal Storage System

Surface treatment: Hot Dip Galvanized
Steel Material: Q235/Q355B,45#,40Cr
Certificate: SGS ISO CE
Design Standard: Customized
Paint Color: Customized
Roof Cover: Steel Panel / FRP Panel
Service: Excellent After-sales Service
Size: Customized
Anti-rust treatment: Epoxy Zinc Rich Primer


Supply Ability

Supply Ability:         2000 Metric Ton/Metric Tons per Month

Packaging & Delivery

Packaging Details
1) Steel structure components will be in nude packaging with proper protection.
2) Sandwich panels will be packed with plastic film.
3) Doors and windows will be packed with bubble plastic.
4) Bolts and other accessory will be packed in wood boxes.
Normally is 40’HQ and 40’OT container.
If you have specifical requirements,40GP and 20GP container is ok.
Lead Time :
Quantity(Square Meters) 1 – 2000 2001 – 5000 5001 – 10000 >10000
Est. Time(days) 25 35 45 To be negotiated

Product Paramenters

The installation is simple. We can provide technical support for installation.

As for the transportation of the steel components of the Dome Coal Storage, we adopt the overall packing and container transportation to avoid the damage of the steel members during the transportation process.

We have professional designers and engineers who can provide professional design proposals and suggestions for you free of charge according to your requirements. You can contact us at any time to tell us your requirements.

Product Name Manufacture Steel Structure Building Mobile Aircraft Hangar Roofing Construction Price
Brand SAFS
Size Customized according to customer requirements
Steel Material Q235B/Q355B,45#,40Cr
Design Standard GB,AS,ES,NSCP
Certificates SGS, BV, ISO, CE and customer-specified inspection agencies
Warranty Main structure warranty for 50 years
Shipping Shipped in 60-90days after the payment
Installation Supervision installation
Packaging Details Special package for spatial structure materials


1. Who are we?
We are based in Jiangsu, China, start from 2019,sell to North America(10.00%),Northern Europe(10.00%),Africa(9.00%),Domestic Market(8.00%),Central America(8.00%),South Asia(8.00%),Southeast Asia(8.00%),Oceania(7.00%),Eastern Asia(6.00%),Southern Europe(6.00%),Mid East(5.00%),Eastern Europe(5.00%),Western Europe(5.00%),South America(5.00%). There are total about 201-300 people in our office.

2. How can we guarantee the quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?

4. Why should you buy from us, not from other suppliers?
We have rich technology experience and professional technical support and also a precise high-level process. And also, we can provide product packaging and transportation, safe and convenient installation guidance service, as well as perfect after-sales service.

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;

Drawings & Quotation

1) Customized design is welcomed.

     Welcome to send us your drawings, we will quote you within 1 day.

     A. Customers have the drawings
          We can provide you the full service of production, shipment, and installation guide, which is high quality and low cost. Because we
          own all kinds of technical facilities, complete test instruments, and advanced production processes.
     B. No drawings
          Our excellent design team will design the light steel structure Gymnasium/warehouse/workshop/poultry house/hall dome coal storage system for you.

2) We have an excellent design team. According to the requirements of different projects and clients, we will supply different designs and steel products. In order to give you an exact quotation and drawings, please let us know the following information. We will quote for you promptly.

Basic design requirements of steel structure indoor Gymnasium

Basic Design Requirements
1.Project location 5.Length (sidewall,m) 9.Window quantity, size
2.Snow load 6.Width (end wall, m) 10.Door quantity, size
3.Wind load 7.Wall Height (eave, m)

11.Brickwall needed or not. If yes, 1.2m high or 1.5m high

4.Seismic magnitude 8.Middle column allowed or not

12.Crane needed or not

13.Thermal insulation. If yes, EPS, fiberglass wool, Rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former.


   Engineering Design Software:

  AutoCAD,PKPM,MTS,3D3S,Tarch,Tekla Structures(Xsteel)V12.0.etc

Dome Coal Storage
Items Specifications
Main Steel Frame Column Q235B,Q355B Welded H Section Steel
Beam Q235B,Q355B Welded H Section Steel
Secondary Frame Purlin Q235B C and Z Purlin
Knee Brace Q235B Angle Steel
Tie Rod Q235B Circular Steel Pipe
Brace Q235B Round Bar
Vertical & Horizontal support Q235B Angle Steel, Round Bar, or Steel Pipe
Maintenance System Roof Panel

EPS, Glass Fiber, Rock Wool, Pu Sandwich Panel

Corrugated Steel Sheet

Wall Panel

EPS, Glass Fiber, Rock Wool, Pu Sandwich Panel

Corrugated Steel Sheet

Accessories Window Aluminum Window, Plastic Steel Window
Door Aluminum Door, Rolling Metal Door
Rainspout PVC
Fastener High Strength Bolts, Normal Bolts, Chemical Bolts
Ventilation System Natural Ventilator, Ventilation Shutters
Live Load on Roof In 120kg Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-Resistance 8 Grades
Structure Usage Up to 50 years
Temperature Suitable temperature -50°C~+50°C
Certification CE, SGS,ISO9001:2008,ISO14001:2004
Finishing Options Vast array of colors and textures available
